MiSTer FPGA USB Hub + USB Bracket
Expand your MiSTer FPGA's USB connectivity with this 7-port USB hub. Factory assembled and tested, version 2.1 provides reliable connections for controllers, keyboards, and storage devices.
Includes
- USB Hub board (v2.1)
- USB bracket for front-panel USB access
- 4× 14mm standoffs for secure installation
Ports
- 7× USB data ports (active, directly under DE10-Nano)
- 1× USB power-only port (rear, for charging or power-hungry devices)
Installation
Connects directly to the DE10-Nano's USB header. The included bracket mounts to the front of the board stack, providing easy USB access.
Compatibility
Works with all MiSTer IO boards. Designed for use with the Aluminum Armor case.
Power options
This USB hub requires some form of external power to the rear DC barrel jack
- DC Jumper (included with the IO Analog Pro and IO Direct boards)
- In-Line Power switch + Splitter
- Separate 5V power supply (5.1mm x 2.1mm center positive polarity)
